Item

5000W

blade diameter

5m

material of the blades

  Fiberglass-Reinforced Plastic

rated rotor speed

220r/min

rated speed

9m/s

rated Power

5000W

max Power

6000w

Max start torque N/M

＜1.0

output voltage

120V/240V customization

start up wind speed

3(m/s)

work speed

3-25(m/s)

security wind speed

 50(m/s)

height of guy cable tower

9(m)

generator type

3-phase AC PM

top quality except tower

180kg

Suggest batteries

    16pcs 12v200ah

Service life

  >15 years

output controller system

Off grid controller and inverter

Mated solar panel

120v600w--1300w

Class of insulation

B

Material of enclosure

20# seamless tube

Material of magnet steel

neodymium-iron-boron 38sh

Material of stator

QZY-2/180/470

Corrosion prevention

Zinc coated、painting

Blades shape

3 FRP blades

Over speed protection

Yaw automatically, electromagnetism protection
