The safety protection of generator operation by variable pitch

The safety protection of wind turbines is not good, and the impellers will turn faster and faster when there is a strong wind, which will eventually cause the generator to burn out. Once the generator burns out, the impeller will stop rotating. Our company has independently developed and launched a wind turbine system with generator power variable pitch, which has been operating safely in the market for many years, running well, and there has been no burn-in accident. At the rated speed of the wind turbine, once the rated speed is exceeded during operation, its own magnetic resistance torque will force the blades of the wind turbine to change pitch (feathering pitch mode), and adjust the speed to achieve a stable output power of the generator. At present, our company has launched a total of horizontal axis reluctance variable pitch wind turbines: 3kw, 5kw, 15kw, 10kw, 20kw, 30kw, 50kw, 60kw, 75kw, 100kw and other series of products. Among them, the 3kw and 5kw models are upwind with tail rudder. Other specifications are: downwind without tail rudder.

1.2. Model definition

Example: XGBJ10KW

XG: manufacturer

BJ: variable pitch series

10KW: rated power of the wind turbine

1.3 Advantages

1. It adopts direct-drive permanent magnet generator, high-efficiency rare earth materials, and the shell is made of carbon steel.

2. The structure of the wind wheel is simple, and the hub adopts a mature variable pitch structure, without complicated moving mechanical parts, and the failure rate is extremely low.

3. Six high-end transmission slip rings are used to conduct electricity, and there is no twisting cable phenomenon.

4. There is no rigid drive mechanism for the vertical shaft of the gyratory, and only conventional bearings are used. This structure can easily resolve the jitter and vibration caused by the unstable air flow, which is beneficial to improve the life of the wind turbine.

5. The generator efficiency is above 90%, and the wind energy utilization coefficient is 42%.

6. The unique and simple control method, automatic windward, effectively improves the working efficiency of the wind turbine; fully utilizes the permanent magnet generator's own power to control the pitch of the blades, achieves the best state of power generation, and increases the annual power generation by more than 30%.

7. With automatic electromagnetic unloading function.

8. Adopt a unique sealing structure to achieve complete moisture-proof and dust-proof
