Rated power

50KW

Max power

55KW

Blades diamter

16.0m

Blades material

FRP

Rated rpm

75r/min

Start wind speed

3(m/s)

Rated wind speed

10(m/s)

Working wind speed

4-25m/s

Safe wind speed lower tan

50m/s

Motor type

Direct drive permanent magnet generator 3-phase AC PM

Output voltage

DC360v-DC520v

Insulation level

B

Working temperature

-25℃ - 55℃

yaw mode

Yaw automatically

Overspeed protection

Pitch control over speed protection

Ausiliary power supply

no

Tower type

Guy cable tower or mono pole tower

Tower height

18-24m

Noise level

<70dB

Top weight

3000kg

IP code

IP54
